In a recent video, YouTuber Robert Murray-Smith demonstrates the diversity of differential gears and their potential for 3D printing. Differential gears, known from the automotive industry, can be found in various applications – from vehicles to clocks and robotic systems.
Murray-Smith explains how different types of differential gears work. In addition to the classic ring-and-pinion type from motor vehicles, he also presents lesser-known variants, such as the epicyclic differential gear for all-wheel drives.
Of particular interest to 3D printing enthusiasts is Murray-Smith’s demonstration of a hypocycloidal differential gear. This variant, which is based on cycloidal gear profiles, is relatively easy to produce using 3D printers. In the video, Murray-Smith shows a model that he designed and printed himself.
The advantages of the hypocycloidal design lie in its compact construction and the possibility of realising high transmission ratios. This makes it particularly attractive for applications in robotics, where weight and size are critical factors.
Murray-Smith makes the 3D models of its designs available free of charge on the Thingiverse platform (Hypocycloid Differential and Hypocycloid Gear). This enables interested makers to rebuild and further develop the concepts.
